Barbed wire machine can be classified into three types:
CS-A normal double twisted barbed wire machine;
CS-B single twisted barbed wire machine;
CS-C reverse twisted barbed wire machine
CS-A It is composed of two parts connecting wire winding and wire winding and twisting, and is equipped with four wire feeding reels. The parts of the machine are coordinated and the action is level. The machine is mainly suitable for the production of various multi-strand barbed wire mesh machines. The materials used should conform to Stable, flexible and reliable operation
The power is 3 kw, voltage is 380V/50HZ (can be customized), main machine size is 2000 mm*1200mm*1400mm,auxiliary is 2000mm *650 mm*800mm, can produce barbed wire with main wire 2.0mm-3.0mm, barb wire 1.8mm-2.4mm
CS-B The single-strand barbed wire mesh machine is composed of two parts: connecting wire winding and winding, and is equipped with three wire reels. The machine moves smoothly, has low noise, high production safety, low energy consumption, high production efficiency, and adopts advanced Electronic counting control.
This type machine power is 3kw, voltage is 380V/50HZ, machine size 2700mm*1200mm*1500mm, weight is 800kg, main wire diameter 2.2-3.0mm, barb wire diameter can be 1.8-2.4mm
CS-C The positive and negative twisting barbed wire mesh machine consists of two parts: positive and negative twisting, puncture winding and friction rope winding, and it is equipped with four winding reels. Convenient operation, stable action, low noise, low energy consumption, and adopts advanced electronic counting control
Reverse twisted barbed wire machine can produce reverse twisted barbed wire,power is 2.2KW, voltage can be customized,The finished product–reverse twisted barbed wire will be much firm than that of other two types barbed wire
